[Discontinued Product]Handheld Spectrum Analyzer MSA338TG
Measurement Frequency : 50kHz to 3.3GHz
Built-in TG from 5MHz to 3.3GHz
Features
| Measurement Frequency | 50kHz to 3.3GHz |
|---|---|
| Applications | Frequency characteristics measurement of electronic component/circuit and return loss measurement. |
| Average Noise Level |
|
| Built-in TG from 5MHz to 3.3GHz | Tracking Generator added to MSA338 enables the measurement and evaluation of amplitude frequency characteristics of filter, amplifier, electronic parts or circuit. |
Library
Products Catalog
Technical report
Measurement of radio wave of wireless LAN by MSA338
Floor arrangement The measurement example using MSA338 is explained by “Floor arrangement” of the figure below. The electric field strength is measured in th e parts enclosed with circle from […]
Measurement by MSA338 before installing wireless LAN
The radio wave environment around the installation place must be measured before the wireless LAN is installed, and then the spot installed and the channel used are decided. The setting […]
Measurement in band from 9 to 13GHz by parabolic antenna with down-converter
Concrete application example The signal of band from 7.9 to 14.5GHz is received by a parabolic antenna, and then it is converted to the lower frequency from 50kHz to 3.3GHz […]
Instruction manual
