[Discontinued roduct]Handheld Spectrum Analyzer MSA338

The most popular model in MSA 300Series.
Measurement Frequency : 50kHz to 3.3GHz

Features

Measurement Frequency50kHz to 3.3GHz
ApplicationsCellular phone, 2.4GHz wireless LAN, 2.5GHz WiMAX, RF-ID, Broadcasting
Average Noise Level
  • Average Noise Level:-117dBm@1GHz
  • Sweep Mode:-117dBm@cf 1GHz,RBW 3kHz

Library

Products Catalog

Spectrum Analyzer MSA300
MICRONIX Products DIGEST catalog

Technical report

Technical info
Measurement of radio wave of wireless LAN by MSA338

Floor arrangement The measurement example using MSA338 is explained by “Floor arrangement” of the figure below. The electric field strength is measured in th e parts enclosed with circle from […]

Technical info
Measurement by MSA338 before installing wireless LAN

The radio wave environment around the installation place must be measured before the wireless LAN is installed, and then the spot installed and the channel used are decided. The setting […]

Technical info
Measurement in band from 9 to 13GHz by parabolic antenna with down-converter

Concrete application example The signal of band from 7.9 to 14.5GHz is received by a parabolic antenna, and then it is converted to the lower frequency from 50kHz to 3.3GHz […]
